Generator / Alternator 210477A ERA
Stoc furnizor
Cod produs
210477A
Cod EAN
8053379008568
Producător
ERA
Disponibilitate
În stoc furnizor
Descriere și detalii
Generator / Alternator 210477A ERA
Tensiune [V]:
14
Curent de incarcare generator [A]:
110
Identificare constructie stecher:
B+COM
Fulie curea Ø [mm]:
55
Role:
cu rola curea cu cuplaj unisens
alternativ:
Directia de rotatie:
rotatie contrar acelor de ceasornic
Numarul gaurilor de fixare:
2
Numar de striatii:
6
Set reparatie alternativ:
210477
Distanta de la fulie la generator [mm]:
47
- RENAULT
- 23 10 085 78R
- RENAULT
- 77 01 475 896
- RENAULT
- 77 01 476 812
- RENAULT
- 77 11 368 380
- RENAULT
- 77 11 368 719
- RENAULT
- 82 00 390 675
- RENAULT
- 82 00 410 681
- RENAULT
- 82 00 660 033
- RENAULT
- 82 00 667 614
- RENAULT
- 82 00 772 726
| Marcă | Model | Tip | An | Caroserie | KW | CP | CCM | Motor |
|---|---|---|---|---|---|---|---|---|
| DACIA | LOGAN (LS_) | 1.6 16V Flexifuel | 07/2010 – | limuzina | 77 | 105 | 1598 | motor pe benzina |
| PEUGEOT | 307 SW (3H) | 1.6 HDI 110 | 11/2003 – 12/2007 | combi | 80 | 109 | 1560 | motor diesel |
| PEUGEOT | 308 I (4A_, 4C_) | 1.6 16V | 09/2007 – 10/2014 | hatchback | 88 | 120 | 1598 | motor pe benzina |
| RENAULT | CLIO II (BB_, CB_) | 1.4 16V (B/CB0L) | 10/1999 – 09/2004 | hatchback | 70 | 95 | 1390 | motor pe benzina |
| RENAULT | CLIO II (BB_, CB_) | 1.4 16V (B/CB0P, BB13) | 02/2000 – 07/2008 | hatchback | 72 | 98 | 1390 | motor pe benzina |
| RENAULT | CLIO II (BB_, CB_) | 1.6 16V (BB01, BB0H, BB0T, BB14, BB1D, BB1R, BB2KL, BB3G... | 09/1998 – 04/2005 | hatchback | 79 | 107 | 1598 | motor pe benzina |
| RENAULT | CLIO II (BB_, CB_) | 1.5 dCi (B/CB3M) | 06/2005 – 12/2010 | hatchback | 47 | 64 | 1461 | motor diesel |
| RENAULT | CLIO III (BR0/1, CR0/1) | 1.4 16V | 06/2005 – 12/2012 | hatchback | 72 | 98 | 1390 | motor pe benzina |
| RENAULT | CLIO III (BR0/1, CR0/1) | 1.6 16V (BR09, BR0T, CR09, CR0T) | 06/2005 – 10/2007 | hatchback | 65 | 88 | 1598 | motor pe benzina |
| RENAULT | CLIO III (BR0/1, CR0/1) | 1.6 16V (BR05, BR0B, BR0Y, BR15, BR1J, BR1M, BR1Y, CR0B,... | 06/2005 – 12/2014 | hatchback | 82 | 112 | 1598 | motor pe benzina |
| RENAULT | CLIO III (BR0/1, CR0/1) | 1.6 16V GT (BR10, CR10) | 06/2009 – 12/2014 | hatchback | 94 | 128 | 1598 | motor pe benzina |
| RENAULT | CLIO III (BR0/1, CR0/1) | 1.5 dCi | 06/2005 – 12/2012 | hatchback | 47 | 64 | 1461 | motor diesel |
| RENAULT | CLIO III (BR0/1, CR0/1) | 1.5 dCi | 05/2005 – 11/2010 | hatchback | 48 | 65 | 1461 | motor diesel |
| RENAULT | CLIO III (BR0/1, CR0/1) | 1.5 dCi (C/BR0G, C/BR1G) | 06/2005 – 12/2012 | hatchback | 50 | 68 | 1461 | motor diesel |
| RENAULT | CLIO III (BR0/1, CR0/1) | 1.5 dCi (BR17, CR17) | 06/2005 – 12/2012 | hatchback | 63 | 86 | 1461 | motor diesel |
| RENAULT | CLIO III (BR0/1, CR0/1) | 1.5 dCi (BR0H, CR0H, CR1S, BR1S) | 06/2005 – 12/2014 | hatchback | 78 | 106 | 1461 | motor diesel |
| RENAULT | CLIO III Grandtour (KR0/1_) | 1.4 16V | 11/2007 – 12/2012 | combi | 72 | 98 | 1390 | motor pe benzina |
| RENAULT | CLIO III Grandtour (KR0/1_) | 1.6 16V (KR0B) | 11/2007 – 12/2012 | combi | 82 | 112 | 1598 | motor pe benzina |
| RENAULT | CLIO III Grandtour (KR0/1_) | 1.6 16V (KR10) | 11/2007 – 12/2012 | combi | 94 | 128 | 1598 | motor pe benzina |
| RENAULT | CLIO III Grandtour (KR0/1_) | 1.5 dCi | 11/2007 – 12/2012 | combi | 48 | 65 | 1461 | motor diesel |
| RENAULT | CLIO III Grandtour (KR0/1_) | 1.5 dCi (KR0G) | 11/2007 – 12/2012 | combi | 50 | 68 | 1461 | motor diesel |
| RENAULT | CLIO III Grandtour (KR0/1_) | 1.5 dCi (KR0F) | 11/2007 – 12/2012 | combi | 63 | 86 | 1461 | motor diesel |
| RENAULT | CLIO III Grandtour (KR0/1_) | 1.5 dCi (KR0H, KR1S) | 02/2008 – 12/2012 | combi | 78 | 106 | 1461 | motor diesel |
| RENAULT | FLUENCE (L3_) | 1.6 16V (L301, L30F, L30P, L30R) | 02/2010 – | limuzina | 81 | 110 | 1598 | motor pe benzina |
| RENAULT | FLUENCE (L3_) | 1.6 16V (L301, L30P, L30R) | 02/2010 – | limuzina | 82 | 111 | 1598 | motor pe benzina |
| RENAULT | GRAND SCÉNIC II (JM0/1_) | 1.6 | 06/2006 – 11/2008 | microbus | 77 | 105 | 1598 | motor pe benzina |
| RENAULT | GRAND SCÉNIC II (JM0/1_) | 1.6 | 06/2006 – 11/2008 | microbus | 82 | 112 | 1598 | motor pe benzina |
| RENAULT | GRAND SCÉNIC II (JM0/1_) | 1.6 Flex | 06/2006 – 06/2009 | microbus | 82 | 112 | 1598 | motor pe benzina |
| RENAULT | GRAND SCÉNIC II (JM0/1_) | 1.6 | 04/2004 – 08/2006 | microbus | 83 | 113 | 1598 | motor pe benzina |
| RENAULT | GRAND SCÉNIC II (JM0/1_) | 1.5 dCi (JM02, JM13) | 04/2004 – 11/2008 | microbus | 74 | 101 | 1461 | motor diesel |
| RENAULT | GRAND SCÉNIC III (JZ0/1_) | 1.6 16V (JZ0U) | 02/2009 – 09/2016 | microbus | 81 | 109 | 1598 | motor pe benzina |
| RENAULT | GRAND SCÉNIC III (JZ0/1_) | 1.6 E85 (JZ03, JZ1Y) | 02/2009 – 09/2016 | microbus | 81 | 110 | 1598 | motor pe benzina |
| RENAULT | KANGOO (KC0/1_) | 1.6 16V bivalent | 06/2005 – | microbus | 60 | 82 | 1598 | motor pe benzina |
| RENAULT | KANGOO (KC0/1_) | 1.6 16V | 06/2001 – 03/2018 | microbus | 70 | 95 | 1598 | motor pe benzina |
| RENAULT | KANGOO (KC0/1_) | 1.6 16V 4x4 (KC0P, KC0S, KC0L) | 10/2001 – | microbus | 70 | 95 | 1598 | motor pe benzina |
| RENAULT | KANGOO / GRAND KANGOO II (KW0/1_) | 1.6 16V (KW03, KW09, KW0D, KW0U, KW0W, KW13) | 02/2008 – | microbus | 78 | 106 | 1598 | motor pe benzina |
| RENAULT | KANGOO / GRAND KANGOO II (KW0/1_) | 1.6 16V FLEX (KW01) | 02/2008 – | microbus | 78 | 106 | 1598 | motor pe benzina |
| RENAULT | KANGOO BE BOP (KW0/1_) | 1.6 (KW0D) | 02/2009 – 12/2012 | microbus | 78 | 106 | 1598 | motor pe benzina |
| RENAULT | LAGUNA I (B56_, 556_) | 1.6 16V (B568, B561) | 11/1997 – 03/2001 | hatchback | 79 | 107 | 1598 | motor pe benzina |
| RENAULT | LAGUNA I Grandtour (K56_) | 1.6 16V (K568) | 11/1997 – 03/2001 | combi | 79 | 107 | 1598 | motor pe benzina |
| RENAULT | LAGUNA II (BG0/1_) | 1.6 16V (BG0A, BG0L) | 03/2001 – 05/2005 | hatchback | 79 | 107 | 1598 | motor pe benzina |
| RENAULT | LAGUNA II (BG0/1_) | 1.6 16V (BG1G, BG1H) | 02/2005 – 08/2007 | hatchback | 82 | 112 | 1598 | motor pe benzina |
| RENAULT | LAGUNA II Grandtour (KG0/1_) | 1.6 16V (KG0A, KG0L) | 03/2001 – 12/2007 | combi | 79 | 107 | 1598 | motor pe benzina |
| RENAULT | LAGUNA II Grandtour (KG0/1_) | 1.6 16V | 02/2005 – 08/2007 | combi | 82 | 112 | 1598 | motor pe benzina |
| RENAULT | LAGUNA III (BT0/1) | 1.6 16V (BT04, BT0D, BT0U) | 10/2007 – 12/2015 | hatchback | 81 | 110 | 1598 | motor pe benzina |
| RENAULT | LAGUNA III Grandtour (KT0/1) | 1.6 16V (KT0D) | 10/2007 – 12/2015 | combi | 81 | 110 | 1598 | motor pe benzina |
| RENAULT | LOGAN I (LS_) | 1.6 (LS0L, LS09, LS0V, LS0P, LS18, LS1S, LS1V, LS1Y,... | 04/2007 – 10/2013 | limuzina | 77 | 105 | 1598 | motor pe benzina |
| RENAULT | LOGAN I combi (KS_) | 1.6 (KS0L, KS0M, KS0P, KS1S) | 04/2007 – | combi | 77 | 105 | 1598 | motor pe benzina |
| RENAULT | MEGANE I (BA0/1_) | 1.4 16V (BA0D, BA1H, BA0W, BA10) | 03/1999 – 08/2003 | hatchback | 70 | 95 | 1390 | motor pe benzina |
| RENAULT | MEGANE I (BA0/1_) | 1.6 16V (BA04, BA0B, BA11, BA1J, BA16, BA19, BA1K, BA1V,... | 03/1999 – 08/2002 | hatchback | 79 | 107 | 1598 | motor pe benzina |
